MES-2500D-TMagnetic Incremental Rotary
Encoder
MES： 40 Magnetic Encoder
Resolution：10PPR~2500PPR (10=10PPR / 500=500PPR / 2500=2500PPR)
Output Method：Non=NPN+PNP(Push-Pull), D=Line Driver
Option：T=Phase
T output appended, PG=M12 Lead Wire
Note:1. Pulse Per Revolution(PPR)：10,20,30,40,50,60,100,120,150,180,200,250,300,360,400,500,512,600,720,800,1000,1024,1200,1500,1800,2000,2048,2500
Note:2. It is accepted to manufacturer for special
resolution!
◆
Electrical Specification /
電氣規格
|
Output model 輸出型式 |
Push - Pull
|
Line Driver
|
|
Operating voltage 工作電壓 |
5 ~ 30VDC |
5VDC
±10% |
|
Output method
輸出方式 |
NPN + PNP |
Line driver IC |
|
Response frequency
響應頻率 |
30K Hz min.. |
|
Current consumption
耗電流 |
40 mA max. |
|
Ripple of power 電源漣波 |
10﹪peak
to peak |
|
Output current 輸出電流 |
150mA max. |
20mA max. |
|
Protection circuit 保護回路 |
Short circuit & polarity reversed protection |
Polarity reversed protection |
|
Voltage drop
輸出壓降 |
0.6V max. |
|
Residual voltage 殘餘電壓 |
0.1V max. |
|
Leakage current
洩漏電流 |
0.1mA max. |
|
Noise resistance 抗干擾 |
2kv /1μs |
|
Dielectric strength 電介強度 |
2.5kv / 1 minute min. |
|
Insulation strength 絕緣強度 |
100 MΩ / 500vdc |
|
Approval
安規 |
CE / RoHS |
◆ Mechanical Specification /
機械規格
|
Specification 規格 |
Data |
|
Starting torque 起動力矩 |
0.098 kg-m |
|
Shaft moment of inertial 慣性力矩 |
1x10-6
kg-m2 |
|
Shaft loading 轉軸負載 |
Radial＜300
kg；Thrust
axial＜200kg |
|
Rotational speed max. 最大轉速 |
6000 RPM |
|
Housing material 外殼材質 |
Intensive PPS |
|
Shaft material 轉軸材質 |
SUS-316 |
◆
Environment Specification /
環境規格
|
Specification
規格 |
Data |
|
Operating circumstance 工作環境 |
-25℃
~ +70℃；85%RH
max. No condensation |
|
Vibration resistance 抗振動 |
10 ~ 55 Hz / 1.5 mm
； 2 Hr/ X.Y.Z direction each |
|
Shock resistance 抗沖擊 |
490m/s2
with 11ms in X.Y.Z direction 3times each |
|
Protection class 保護等級 |
IP-54 |
◆
Outline dimension /
外形圖
◆
Connections /
接線圖
|
 |
|
Push-Pull |
Line driver |
|
Color |
Description |
Color |
Description |
Color |
Description |
|
Brown |
+ V |
Brown |
+ V |
Blue |
0 V |
|
Blue |
0 V |
Black |
Phase A |
Black/Red |
Phase
A |
|
Black |
Phase A |
White |
Phase B |
White/Red |
Phase B |
|
White |
Phase B |
Yellow |
Phase Z |
Yellow/Red |
Phase Z |
|
Yellow |
Phase Z |
|
|
|
|
|
